Foxy Pro Crane - Platform 3

max. Height: 6,1 m / 20 ft

max. Payload: 250 kg / 550 lbs

needed weights: 43

1x 156773:   Central Pivot Section

2x 156909:   Rear Bracing

2x 136770:   Outrigger Tail

1x 156819:   Trapezoid

4x 302256:  Outrigger 150 cm

2x 302090:   Anchor Pole Axis

2x 157124:   Anchor Pole front, variable

2x 157129:   Base Anchor Pole

2x 157381:   Anchor Pole Extension

1x 169310:   Counter Weight Bucket (39 w.)

1x 301850: Add. Counterweight Bucket (4 w.)

1x 310949:   Nose Mount

1x 132662: Platform for Nose Mount
