Foxy Pro Crane - Platform 2.1

max. Height: 4,9 m / 16 ft

max. Payload: 265 kg / 585 lbs

needed weights: 30

1x 156773:   Central Pivot Section

2x 156909:   Rear Bracing

2x 136770:   Outrigger Tail

3x 302256:  Outrigger 150 cm

1x 314914:   Counter Weight Bucket (45 w.)

1x 310949:   Nose Mount

1x 132662: Platform for Nose Mount

1x 156819:   Trapezoid

2x 302090:   Anchor Pole Axis

2x 157124:   Anchor Pole front, variable

2x 157129:   Base Anchor Pole

2x 157381:   Anchor Pole Extension

‍

‍
